Altus PO6001 Analog Base Spring I/O
Last unit- Code
- WS2608
- GTIN
- 4015081008667
- Dispatch
- Within 1 business day for in-stock items.
- Top seller on Mercado Livre and eBay
- Business invoicing available
- Dispatch within 1 business day
- Secure payment
Choose the buyer type - we open the form with this product already filled in.
Main item details
- Brand
- ALTUS
- SKU / Internal code
- WS2608
- GTIN
- 4015081008667
- Condition
- Condition shown in specs
- Stock
- Last unit
- Brand
- Altus
- Model
- PO6001
- Analog Bases
- 3 A, 250 Vac fuses for protection of
- Dimensions See item
- Physical Dimensions
- Date
- 11/30/2023
- Weight
- 0.176 kg
- Measurements
- 9x10x6
- Locator
- B2P3A
About this item
Altus Digital I/O Base PO6001
New product out of manufacturer's box
An analog I/O (Input/Output) base refers to a physical structure or module in an automation or control system that allows the connection of analog I/O modules. These modules are designed to handle analog signals, which are continuously variable as opposed to digital signals that have discrete states, such as 0 or 1.
In industrial control and automation systems, analog input can represent a wide variety of values, such as temperatures, pressures, liquid levels, speeds, and other physical quantities that can be measured continuously. Analog outputs, on the other hand, are used to send proportional signals to external equipment or processes that require continuous control.
The analog I/O base provides a means to connect and integrate specific analog input and output modules into a larger system. These modules typically include analog-to-digital converters (ADCs) for inputs and digital-to-analog converters (DACs) for outputs.
The set of integrated bases of the Ponto Series allows direct connection of field signals to electronic modules.
This system eliminates the need for intermediate terminals and fuse holders in the cabinet and allows hot swapping of the
modules without cable disconnection. The bases are available with highly reliable spring-type terminals. The spectrum of
available options covers all types of needs for process automation or machine applications.
Its main features are:
- High point density, up to 32 points per base
- Available with spring-type terminals
- Available with fuse holders
- Analog version with ambient temperature sensor element (cold junction)
- Compatible with GBL communication standard
- Point identification on terminals
- Connection between bases by sliding connectors
- Mechanical keys to restrict module mounting
- Automatic addressing
- DIN rail TS35 mounting
Product Type Ponto Series IP20 Module Bases
Current capacity
See Technical Characteristics document of the module used
Terminal configuration 3 rows of 18 terminals
Configurable parameters None
Protections Fuse per point or per group on bases with fuse
Analog Bases: 3 A, 250 Vac fuses for protection of
power supply of sensor elements and 32 mA fuses for
current signal protection
External power supply voltage Possible by connecting terminals (A) and (B) in the manner indicated by the
Technical Characteristics document of the module used
Terminals for logic
Terminals for ground
Between Terminals
1500 Vac / 1 minute
1500 Vac / 1 minute
1500 Vac / 1 minute
Current consumption of the
Maximum operating temperature
60 oC in non-condensing humidity
Dimensions See item: Physical Dimensions
Standards met IEC 61131
Date: 11/30/2023
Measurements: 9x10x6
Dear customers, if the material is for resale, the ST (Tax Substitution) value may apply. If the operation is subject to this tax, the responsibility for payment rests solely with the buyer.
Cabo Eletro Comercial LTDA thanks you.
5 reasons to buy from Cabo Eletro
- 01 Proven reputation Top seller on Mercado Livre and eBay, with a public sales history.
- 02 Traceability and invoicing Business invoicing and electronic invoices are available for purchases.
- 03 Hard-to-find inventory 12,000+ SKUs, including discontinued and replacement items.
- 04 Fast dispatch In-stock items ship within 1 business day after confirmation.
- 05 Technical support We help validate the code and application before purchase.
Buying multiple items? Request an email quote
Send this item with other codes or SKUs and receive a consolidated quote with invoice details and volume conditions. We support individual buyers, companies, and international buyers.
Em caso de revenda, entre em contato antecipadamente para consultar valores referentes à Substituição tributária.
Verifique na descrição abaixo o estado do item anunciado. Por lá é indicado se o item é novo, usado e todas as outras informações que o comprador precisa saber antes de realizar a compra.
Altus Digital I/O Base PO6001
New product out of manufacturer's box
Brand: Altus
Model: PO6001
An analog I/O (Input/Output) base refers to a physical structure or module in an automation or control system that allows the connection of analog I/O modules. These modules are designed to handle analog signals, which are continuously variable as opposed to digital signals that have discrete states, such as 0 or 1.
In industrial control and automation systems, analog input can represent a wide variety of values, such as temperatures, pressures, liquid levels, speeds, and other physical quantities that can be measured continuously. Analog outputs, on the other hand, are used to send proportional signals to external equipment or processes that require continuous control.
The analog I/O base provides a means to connect and integrate specific analog input and output modules into a larger system. These modules typically include analog-to-digital converters (ADCs) for inputs and digital-to-analog converters (DACs) for outputs.
The set of integrated bases of the Ponto Series allows direct connection of field signals to electronic modules.
This system eliminates the need for intermediate terminals and fuse holders in the cabinet and allows hot swapping of the
modules without cable disconnection. The bases are available with highly reliable spring-type terminals. The spectrum of
available options covers all types of needs for process automation or machine applications.
Its main features are:
- High point density, up to 32 points per base
- Available with spring-type terminals
- Available with fuse holders
- Analog version with ambient temperature sensor element (cold junction)
- Compatible with GBL communication standard
- Point identification on terminals
- Connection between bases by sliding connectors
- Mechanical keys to restrict module mounting
- Automatic addressing
- DIN rail TS35 mounting
Product Type Ponto Series IP20 Module Bases
Current capacity
maximum base
See Technical Characteristics document of the module used
Terminal configuration 3 rows of 18 terminals
Configurable parameters None
Protections Fuse per point or per group on bases with fuse
Analog Bases: 3 A, 250 Vac fuses for protection of
power supply of sensor elements and 32 mA fuses for
current signal protection
External power supply voltage Possible by connecting terminals (A) and (B) in the manner indicated by the
Technical Characteristics document of the module used
Isolation
Terminals for logic
Terminals for ground
Between Terminals
1500 Vac / 1 minute
1500 Vac / 1 minute
1500 Vac / 1 minute
Current consumption of the
busbar
Not applicable
Maximum operating temperature
60 oC in non-condensing humidity
Dimensions See item: Physical Dimensions
Standards met IEC 61131
Date: 11/30/2023
Weight: 0.176
Measurements: 9x10x6
Locator: B2P3A
Dear customers, if the material is for resale, the ST (Tax Substitution) value may apply. If the operation is subject to this tax, the responsibility for payment rests solely with the buyer.
Cabo Eletro Comercial LTDA thanks you.
